Description
Specification
| Main Feature | ||
| Network Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p | |
| Data Transmission Rate | 10/ 100/ 1000 Mbps | |
| MAC Address Table | 8k | |
| Environment | Operating Temperature: 0–50 °C (32–122 °F) Storage Temperature: -40–70 °C (-40–158 °F) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing |
|
| Hardware Features | ||
| Interface | 16× 10/100/1000 Mbps PoE+ RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) 2× 10/100/1000 Mbps non-PoE RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) 2× Combo Gigabit SFP Ports |
|
| LED | Yes | |
| Power Supply | 100–240V AC, 50/60 Hz | |
| Dimensions (L x W x H) | 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm) | |
