MERCUSYS MW325R- 300Mbps Enhanced Wireless N Router

$6.40

  • Maximum coverage – four 5dBi antennas provide up to 500m2 of wireless coverage
  • Enhanced signal – high gain antennas dramatically increase wireless signal strength, size and stability
  • 300Mbps wireless speed – ideal for HD streaming, online gaming, and large file downloads
  • Easy installation – intuitive webpage guides you through the setup process in minutes
  • *Range specications are based on performance test results. Real performance varies in accordance with applications and environmental conditions.

Description

Maximize your Wi-Fi Coverage

300Mbps Enhanced Wireless N Router | MW325R

Up to 500m2* of Wi-Fi Coverage

The MW325R creates an expansive wireless network that is capable of covering your home with up to 500m2 of wireless coverage. You can enjoy reliable, high performance connections in the living room, the bedroom, or even the backyard.

  • * Range specifications are based on performance test results.
  • Real performance varies in accordance with application and environmental conditions.

Stronger, More Reliable Wi-Fi Signal

In addition to enhanced wireless coverage, the MW325R also provides excellent wireless performance and a strong, stable Wi-Fi signal. With the 300Mbps speed, you can multitask, enjoying streaming video, online gaming, and fast web browsing at the same time.

Powered by Qualcomm

At its core, the MW325R features a Qualcomm chipset that is capable of providing stable wireless and wired connections to multiple devices at the same time.

Four 5dBi Antennas

By combining 2×2 MIMO Technology and four high gain antennas, the MW325R is able to significantly increase its signal transmission and reception capabilities. This means that you do not have to worry about lag or
dropped connections while enjoying onlinegaming and streaming video.

Three-Step Installation

With no need for complicated configuration, you can simply follow the step-by-step
instructions on the intuitive webpage to set up your MW325R in minutes.

  • 1 / Create a unique login password
  • 2 / Choose your Internet service and fill in the required information
  • 3 / Set your wireless network name (SSID) and password

Network Security

Comprehensive security features help your devices form safe connections to the MW325R.

  •  Parental ControlManage when and how connected devices can access the Internet
  •  Guest NetworkKeeps your main network secure by creating a separate network for guests
  •  Advanced EncryptionWPA/WPA2 encryption standards ensure that your wireless connection is safe from intruders

Additional information

Specifications

Dimensions:
(W X D X H) 167 x 118 x 33 mm
Interfaces:
4 10/100Mbps LAN ports
1 10/100Mbps WAN port
Button:
Reset button
External Power Supply:
9VDC/0.6A
Antenna Type:
4 x 5dBi fixed omni directional antennas
Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency: 2.4 – 2.4835GHz
Signal Rate

11n: Up to 300Mbps (Dynamic)

11g: Up to 54Mbps (Dynamic)
11b: Up to 11Mbps (Dynamic)
Reception Sensitivity

270M: -70dBm@10% PER

130M: -74dBm@10% PER

108M: -74dBm@10% PER

54M: -77dBm@10% PER

11M: -87dBm@8% PER

6M: -90dBm@10% PER
1M: -98dBm@8% PER
Certifications CE, ROHS
Package Contents

300Mbps Enhanced Wireless N Router

MW325R

Power adapter

Quick installation guide

Ethernet cable
Environment

Operating temperature: 0⁰C ~ 40⁰C (32⁰F ~ 104⁰F)

Storage temperature: -40⁰C ~ 70⁰C (-40⁰F ~ 158⁰F)

Operating humidity: 10% ~ 90%, non-condensing
Storage humidity: 5% ~ 90%, non-condensing
Transmission Power <20dBm
Wireless Security WPA-PSK / WPA2-PSK
Wireless Functions WDS bridge
WAN Type Dynamic IP/Static IP/PPPoE
Management

Access control

Local management
Remote management
DHCP Server
Port Forwarding Virtual server, UPnP, DMZ
Dynamic DNS Oray
Firewall Security IP and MAC address binding
Protocols IPv4
Guest Network 2.4GHz guest network
