Description
Specifications & Technical Details
| Camera | ||
|---|---|---|
| Image Sensor: | | | 2MP CMOS Image Sensor |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | 1920(H)*1080(V) |
| Min. Illumination: | | | 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR |
| Shutter Time: | | | 1/25(1/30) s to 1/50,000 s |
| Lens: | | | 2.8mm, 3.6mm, 6mm optional |
| Lens Mount: | | | M12 |
| Adjustment Range: | | | Pan: 0 – 360°, Tilt: 0 – 75°, Rotation: 0 – 360° |
| Day& Night: | | | IR cut filter with auto switch |
| Video Frame Rate: | | | 1080p@25fps/1080p@30fps |
| HD Video Output: | | | 1 Analog HD output |
| Synchronization: | | | Internal Synchronization |
| S/N Ratio: | | | More than 62 dB |
| General | ||
| Operating Conditions: | | | -20 °C – 45 °C (-4 °F – 113 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | | | 12 VDC±15% |
| Power Consumption: | | | Max. 4W |
| Weather Proof: | | | IP66 |
| IR Range: | | | Up to 40m |
| Dimension: | | | Φ110 × 93.2 mm(Φ4.33” × 3.67”) |
| Weight: | | | 350 g |
